Can AR Fibers Be Used in Shotcrete and Mortar?

Information Tags

       •      Type: 4-minute read

       •      Audience: Construction professionals, engineers, architects, contractors

Abstract

Discover whether AR fibers can be used in shotcrete and mortar applications, and how they improve crack resistance, flexural strength, and durability. Learn about fiber compatibility, dosage rates, and performance benefits in sprayed concrete and repair systems.

Find the perfect solution for your concrete project. [Explore solutions]

Introduction: Reinforcing Shotcrete and Mortar with AR Fibers

Shotcrete and mortar are essential materials in modern construction, especially for structural repairs, tunnel linings, slope stabilization, and architectural finishes.

While these materials offer high compressive strength, they are inherently brittle and prone to cracking—especially under dynamic loads or environmental stressors.

Enter alkali-resistant (AR) glass fibers, which have proven effective in enhancing the mechanical behavior of cementitious systems. But can AR fibers be used in shotcrete and mortar effectively?

In this article, we explore how AR fibers perform in these applications, their compatibility with spray processes, and how they contribute to long-term durability and structural integrity.

Why AR Fibers Are Suitable for Shotcrete and Mortar

The short answer is yes—AR fibers can be used in shotcrete and mortar, and they offer significant advantages over traditional reinforcement methods.

1. Alkali Resistance in Cementitious Systems

Cement paste is highly alkaline, which can degrade standard E-glass fibers over time. AR fibers, formulated with zirconia content (≥16%), resist chemical attack and maintain performance even after years of exposure.

This makes them ideal for use in:

Sprayed concrete linings

Structural repair mortars

Thin-section overlays

2. Enhanced Crack Control

Fibers help control both early-age shrinkage cracks and later-stage micro-cracks caused by load or environmental stress. In shotcrete, where rapid application and curing create internal stresses, AR fibers provide critical tensile support that improves crack resistance.

3. Improved Flexural and Impact Strength

Unlike synthetic or steel fibers that may settle unevenly or corrode, AR fibers remain uniformly dispersed and active in the matrix, enhancing flexural toughness and impact resistance—key properties for ground support and rehabilitation projects.

Fiber Compatibility with Wet and Dry Shotcrete Processes

There are two primary methods for applying shotcrete: wet-mix and dry-mix. Both are compatible with AR fibers, though some considerations apply:

Process	Suitability for AR Fibers	Notes
Wet-Mix Shotcrete	Excellent	Fibers are added during mixing; better dispersion and lower rebound
Dry-Mix Shotcrete	Good	Fibers must be added post-mixing but pre-nozzle; requires careful handling

For best results, Pioneer Fibre recommends using chopped AR fibers at dosages between 1–3% by weight of cement, depending on the required performance criteria and thickness of the applied layer.

Real-World Applications Using AR Fibers in Shotcrete and Mortar

Several sectors benefit from incorporating AR fibers into shotcrete and mortar, including:

1. Tunnel Linings and Ground Support

Tunnel segments often require thin yet durable linings that resist spalling under fire or mechanical stress. AR fiber-reinforced shotcrete offers enhanced ductility and crack resistance without adding excessive weight.

2. Bridge Deck Overlays

Bridge decks face constant traffic loading and freeze-thaw cycles. Adding AR fibers to mortar overlays increases surface durability and extends service life by minimizing crack propagation.

3. Slope Stabilization and Retaining Walls

In geotechnical applications, shotcrete is used to stabilize slopes and protect against erosion. AR fibers improve the tensile strength of the applied layer, helping it resist cracking due to movement or temperature changes.

4. Architectural Shotcrete

From sculptural elements to façade restoration, architects rely on AR fiber-reinforced shotcrete for its ability to form complex shapes while maintaining structural integrity.

Each of these applications highlights how AR fibers enhance shotcrete and mortar performance beyond basic reinforcement.

See how we’ve helped projects around the world succeed. [View projects]

Dosage and Mixing Recommendations

To ensure optimal performance when using AR fibers in shotcrete and mortar, follow these guidelines:

Dosage Rate: Typically 1–3% by weight of cement (equivalent to 8–25 kg/m³)

Mixing Time: Allow sufficient time for uniform dispersion; avoid over-mixing

Water-Cement Ratio: Maintain proper w/c ratio to prevent fiber floatation or segregation

Admixtures: Use dispersants or superplasticizers if needed to improve workability and fiber distribution

Proper mix design and placement techniques will maximize the benefits of AR fiber reinforcement in your project.

Final Thoughts: Reinforcement Designed for Performance

At Pioneer Fibre, we understand that not all fibers behave the same in high-performance applications like shotcrete and mortar.

Our PIONEER® AR fibers are specifically engineered for use in aggressive cement environments, ensuring long-term durability and mechanical enhancement. Whether you're reinforcing a tunnel lining or restoring an architectural element, choosing the right fiber ensures lasting results.

If you’re considering AR fibers for shotcrete or mortar applications, our technical team is ready to assist with product selection, dosage recommendations, and compatibility testing.

Behind the Innovation: Testing for Real-World Success

We don’t just manufacture fibers—we validate their performance.

Our R&D lab conducts extensive testing on fiber behavior in simulated shotcrete and mortar conditions, including:

Accelerated aging tests

Flexural and tensile strength evaluations

Dispersion and workability assessments

These studies allow us to refine fiber geometry, dosage, and processing techniques to meet the evolving demands of modern construction.

By combining science with real-world experience, we ensure every batch of AR fibers supports superior performance in shotcrete and mortar applications.
