HGM® Basalt
Basalt Fiber for Asphalt Pavements
High-Performance Fiber Solutions for Fiber-Reinforced Asphalt Concrete
What Are Basalt Fibers for Fiber-Reinforced Asphalt Pavements?
PIONEER® HGM® Basalt is a high-performance chopped basalt fiber engineered specifically for asphalt pavements and overlays. Produced from 100% natural basalt rock, these fibers significantly enhance the structural integrity of fiber-reinforced asphalt concrete (FRAC).
By forming a three-dimensional reinforcement network inside hot mix or warm mix asphalt, HGM® Basalt improves resistance to cracking, rutting, fatigue, and deformation under heavy traffic loads and thermal stress. As a mineral fiber with excellent heat, chemical, and UV stability, it provides long-term durability in demanding pavement environments.
Key Benefits of Using Basalt Fiber in Asphalt Pavements
Leverage the core advantages of PIONEER® basalt reinforcement in high-performance asphalt applications:
-
Superior Durability: Significantly reduces cracking, rutting, and fatigue for longer pavement life.
-
High Thermal Resistance: Maintains performance during hot mix production and high-temperature service conditions.
-
Eco-Friendly Mineral Fiber: Sourced from natural basalt, supporting sustainable construction practices.
-
Improved Flexibility & Load Capacity: Helps pavements withstand thermal expansion and heavy traffic.
-
Chemical & UV Resistance: Ensures long-term reinforcement in harsh environmental conditions.
Technical Specifications of Basalt Fiber for Asphalt Reinforcement
Explore the physical and mechanical properties of HGM® Basalt:
-
Material: 100% basalt fiber
-
Fiber Type: Chopped mineral fiber
-
Diameter: ~0.02 mm
-
Nominal Length: 6 mm, 12 mm
-
Tensile Strength: > 1600 MPa
-
Modulus of Elasticity: >75 GPa
-
High Temperature Stability: Excellent
-
Alkali, Acid, and Salt Resistance: High
-
UV Resistance: Excellent
Applicable standards and test methods include:
-
ASTM D7552 — Fiber-Reinforced Asphalt Concrete
-
AASHTO M325 — Fiber Additives for Asphalt Mixtures
How Basalt Fibers Enhance Asphalt Pavements
PIONEER® HGM® Basalt disperses uniformly within asphalt mixtures, forming a multidirectional reinforcement matrix that:
-
Minimizes cracking, rutting, and fatigue
-
Enhances mix stability and cohesion
-
Increases deformation resistance
-
Provides long-term durability in heavy-traffic zones
-
Maintains performance under high heat and severe climate conditions
Asphalt mix reinforced with Basalt fibers
Crack control with Basalt fiber-modified asphalt
Where to Use Basalt Fiber for Asphalt Pavement Reinforcement?
Ideal applications of HGM® Basalt include:
-
Roads and Highways: High-traffic routes needing enhanced durability
-
Pavement Overlays & Rehabilitation: Extending service life of aging surfaces
-
Heavy-Duty Pavements: Airports, industrial parks, bus lanes
-
Extreme Climate Zones: Hot regions, freeze-thaw areas, coastal environments
Hong Kong-Zhuhai-Macao Bridge
Da Nang Pier, Vietnam
Hangzhou Olympic Center
How to Use Basalt Fiber in Asphalt Mixes
PIONEER® basalt fibers integrate seamlessly into hot mix and warm mix asphalt.
Usage Guidelines:
-
Dosage: 1–3 kg per ton of asphalt mix
-
Mixing: Pre-blend with aggregates before adding bitumen
-
Construction: Compatible with standard paving equipment
-
Design: No mix design modification required
Custom Fiber Solutions for Asphalt Projects
PIONEER® provides flexible customization options for asphalt reinforcement:
Lengths:
-
Custom fiber lengths available upon request
Packaging Options:
-
Bulk Ton Bags: For large asphalt plants
-
Low-Melt PE Bags: Clean, efficient dosing during mixing
